Article ID Code:GK-Spe-34
 | |
| Form Factor | 137 × 132 × 55 mm |
| CPU | AMD R7-8745HS (8 cores, 16 threads, 16MB L3 cache, 3.8 – 4.9 GHz, TDP: 45W) AMD R7-8845HS (8 cores, 16 threads, 16MB L3 cache, 3.8 – 5.1 GHz, TDP: 45W) AMD R9-8945HS (8 cores, 16 threads, 16MB L3 cache, 4.0 – 5.2 GHz, TDP: 45W) |
| Video Engine Processor | AMD Radeon™ Graphics |
| Memory | Dual channel DDR5 262PIN 5600MHz SODIMM, up to 64GB |
| Audio | HDA CODEC |
| Storage | M.2 2280 PCIe 4.0 ×4, up to 2 TB |
| I/O Port | 1 × rear USB 3.2 Gen 2 Type-A 1 × rear USB 2.0 Type-A 3 × front USB 3.2 Gen 2 Type-A 1 × front USB 3.2 Gen 2 Type-A (Always On) 1 × USB 4.0 Type-C support Power Delivery / PD in (back panel) 1 × USB 4.0 Type-C support Power Delivery (back panel) 1 × 3.5mm front stereo headset jack 2 × RJ45 (back panel) 2 × HDMI 2.0 (back panel) 1 × DC in (back panel) 1 × Power Button 1 × Kensington Lock 1 × SD Card |
| Internal Connector | 1 × M.2 key-M slot for PCIe 4.0 ×4 or SATA (only for Rembrandt) 1 × M.2 key-B slot (SATA) (only for Rembrandt) 1 × M.2 2230 for WIFI PCIe card only 1 × FAN Wireless Charging power (option) 1 × USB 2.0 1 × USB 2.0 or RS485 Speaker Header (HW design reserved) 1 × 16-pin FPC SATA connector to connect an FFC SATA cable to a 7mm 2.5″ SATA 1 × Power Connector (9V~36V) 1 × RS232 |
| LED | 2 × POWER LED (Power On: White) |
| Ethernet | 10/100/1000/2500 Mbps RJ45 × 2 |
| Wireless LAN | Wi-Fi 6E BT 5.2 |
