Article ID Code:GK-Spe-33
| Form Factor | 112.4 × 112.4 × 37 mm |
| CPU | AMD Ryzen™ 6800 TDP up to 45W |
| Graphics | AMD Radeon™ 680M Graphics |
| Memory | High Speed DDR5, expandable up to 64 GB |
| Audio | HDA CODEC |
| Storage | 1 × M.2 2280 SSD (NVMe x4 Gen 4 or SATA, only for Rembrandt) |
| 1 × M.2 2242 SATA HDD (only for Rembrandt; metal ID not support) | |
| I/O Ports | 1 × Rear USB 3.2 Gen 2 Type-A |
| 1 × Rear USB 2.0 Type-A | |
| 1 × Front USB 3.2 Gen 2 Type-A supports Power Delivery | |
| 1 × Front USB 3.2 Gen 2 Type-A | |
| 1 × USB 3.2 Gen 2 Type-C supports Power Delivery (back panel) | |
| 1 × USB4 supports Power Delivery (back panel) | |
| 1 × 3.5mm front stereo headset jack | |
| 1 × RJ45 (back panel) | |
| 2 × HDMI 2.0 (back panel) | |
| 1 × DC in (back panel) | |
| 1 × Power Button | |
| 1 × SD Card Reader | |
| Internal Connector | 1 × M.2 key-B slot (SATA only for Rembrandt) |
| 1 × M.2 2230 for Wi-Fi PCIe card only | |
| 1 × FAN | |
| 1 × Wireless Charging power (optional) | |
| 2 × USB 2.0 | |
| 1 × Speaker Header (HW design reserve) | |
| 1 × 16-pin FPC SATA connector to connect an FFC SATA cable to a 7mm 2.5" SATA | |
| LED | 2 × POWER LED (Power On: White) |
| Ethernet | Intel 10/100/1000/2500 Mbps RJ45 |
| Wireless LAN | M.2 Wi-Fi 6E Bluetooth 5.2 |
| Kensington Lock | No |
| DTPM 2.0 | Supports fTPM 2.0 |
| Battery | RTC coin battery |
| Adapter | 19V power supply adapter (120W) with geo-specific AC cord (IEC C5) |
| PCBA Dimension | 105.75 × 102.9 × 1.6 mm |
| Certification | CE, FCC, CB, CCC, SRRC, RoHS |
| Operating System | Microsoft Windows 11 Pro (64-bit), supports Modern Standby |
| Accessory | VESA Mount (optional) |
