Article ID Code:GK-Spe-21
| Form Factor | Chassis: 112.4 × 112.4 × 37 mm |
| CPU | 13th Gen Intel® Core™ i9-13900H (14 Cores, 20 Threads, 24MB Cache, up to 5.40 GHz) |
| 12th Gen Intel® Core™ i7-13620H (10 cores, 16 threads, up to 4.9 GHz, L3 cache: 24MB, TDP: 45W) | |
| Graphics | Intel® Iris® Xe Graphics eligible(i9-13900H) |
| Intel® UHD Graphics for 13th Gen Intel® Processors(i7-13620H) | |
| Memory | Dual-channel DDR4 3200 MT/s SODIMM, up to 64GB |
| Storage | 1 × SSD (PCIe Gen 4 ×4), up to 2TB |
| I/O Port | 1 × rear USB 3.2 Gen 2 Type-A, 1 × rear USB 2.0 Type-A |
| 1 × front USB 3.2 Gen 2 Type-A support Power Delivery 1 × front USB 3.2 Gen 2 Type-A | |
| 2 × USB 4 Gen3 Type-C | |
| 1 × 3.5mm front stereo headset jack | |
| 1 × RJ45 (back panel) | |
| 2 × HDMI 2.0 (back panel) | |
| 1 × DC in (back panel) | |
| 1 × Power Button | |
| 1 × SD Card | |
| Internal Connector | 1 × M.2 key-M slot for PCIe Gen 4 ×4 NVMe SSD |
| 1 × M.2 key-B slot (SATA) | |
| 1 × M.2 2230 for WIFI | |
| 1 × FAN | |
| LED | 1 × POWER LED (Power On: White) |
| 1 × Multi LED (M.2 R/W: White, SATA R/W: White, Bluetooth: White) | |
| Ethernet | Intel 10/100/1000/2500 Mbps RJ45 |
| Wireless LAN | M.2 Wi-Fi 6E Bluetooth 5.2 — XB591(MediaTek 7922) |
| Kensington Lock | No |
| DTPM 2.0 | fTPM |
| Battery | RTC coin battery |
| Adapter | 19V 6.32A |
| PCBA Dimension | 105.75 × 102.9 × 1.6 mm |
| Certification | CE, FCC, CB, CCC, RoHS |
| Operating system | Microsoft Windows® 11 (64-bit) |
| Accessory | VESA Mount |
